Fits Front
Fitting Position: Front Axle
 |
Specifications
Brake Disc Thickness: 24mm
Brake Disc Type: Internally Vented
Min Thickness Of Brake Disc: 21.8mm
No. Of Fixing Holes: 2
No. Of Wheel Bolt/ Stud Holes: 5
Surface: Coated
|
 |
Diameter
Centre Diameter: 61mm
Outer Diameter: 280mm
Pitch Circle Diameter: 108mm
|
 |
Dimensions
Height Or Thickness: 44mm
Weight: 7.2kg
|
Make and model this part will fit
Renault Espace III, Grand Espace III, Laguna I, Safrane I, Safrane I 4x4, Safrane II, Scenic I 4x4
Original Manufacturer part number this will replace (OE)
Mercedes Benz: 415 420 00 01, 415 420 07 01
Renault: 77 00 802 231, 77 00 823 515, 77 00 830 283, 77 01 204 305, 77 01 205 231, 77 01 205 843, 77 01 206 198, 77 01 206 198 SK, 77 01 209 839
Other Brands equivalent part number
A.B.S.: 16219, 17980, 17996, 09.8137.11, 09.A727.21
APEC Braking: DSK834, SDK6243
Bendix: 522025, 522071
Borg & Beck: BBD5020, BBD5163
Bosch: 0 986 478 734, 0 986 478 797, 0 986 479 555, 0 986 479 S66, 0 986 BB4 080
Brake Engineering: DI955321, DI956872
Comline: ADC1516V, AND6714
Delphi: BG2697, BG4317, BG4317C
Febi Bilstein 12097
Ferodo: DDF1123, DDF1123-1, DDF1123C, DDF1733, DDF1733-1, DDF1733C, DDF1733C-1
HELLA: 8DD 355 108-631, 8DD 355 116-451, 8DD 355 127-741
Lemforder: 18163 01
Metzger: 6110003, 6110386
Meyle: 16-15 521 0016, 16-15 521 0042, 16-15 521 0042/PD
Mintex: MDC2238, MDC778
Pagid: 50288, 54138, 55024
Topran: 700 817
Trucktec Automotive: 02.35.443
TRW: DF1033, DF4109, DF6110
VAICO: V46-80020
Valeo: 186600, 197485
Fits Makes: Mercedes Benz, Renault
OE Part Number: 4154200001 | 4154200701 | 7700802231 | 7700823515 | 7700830283
Other Part Numbers: DSK834 | SDK6243 | BBD5020 | BBD5163 | 986479555 | 0986479S66
